Standard Tough – Super Low Odor Photopolymer Resin

Packaged in a durable aluminium bottle

• Super low odour resin, compatible with most LCD printers using 405 nm wavelength light.
• 86 shore D hardness, Not brittle, Low Shrinkage
• Faster Printing Speed
• Less irritant
• Less corrosive
• CMYK color mixing

Compatible for monochrome screen printers and color screen printers, printing without residual film or sediment. Enjoy a high successful printing rate.

Properties:
Solidify wavelength: 355nm to 410nm
Viscosity (25C,mPa.s): 200 to 400 mPa s

Flexural strength: 36Mpa to 49 mPa
Flexural Modulus: 900 to 1100 mPa
Tensile strength: 30Mpa to 40 mPa
Elongation at break (%): 32% to 38%
Hardness (D): 85-88

Precautions:
1. Storage
1) Keep away from light and sealed at room temperature.
2) It is recommended to store the resin between 15 Celsius and 35 Celsius in its original container.
Avoid any dusty or moist environments.

2. Usage:
1) Shake well before use. Avoid any direct sunlight during usage.
2) Keep it away from children. Do not ingest.
3) Wear gloves before use to avoid direct skin contact and keep the room ventilated.
4) In case of skin contact please wash immediately with plenty of water. Seek medical advice if necessary.
5) Clean the finished model with alcohol (>95%) for about 30 seconds.

Bottom Exposure Time: 25-50s on mono and 30-70 on colour when layer thickness is 0.05mm.
Normal Exposure Time: 4-8s on mono and 4-16s on colour when layer thickness is 0.05mm.
PS: Exposure time is proportional to layer thickness. The numbers above are for layer thickness 0.05mm.
